Thermally Conductive Potting Silicone for Energy Storage Syst

Product No：HY-9050
Brand：Hong Ye Silicone
Product Usage：HY-9050 is a two-component addtion-cure liquid silicone rubber specially designed for energy storage system battery pack potting and encapsulation. With excellent thermal conductivity and electrical insulation properties, it provides reliable protection for battery modules in demanding operating conditions.

Key Features:
  • Thermal conductivity: ≥0.6 W/mK, efficiently dissipates heat generated during battery charging and discharging
  • Excellent electrical insulation: withstands high voltage environments, prevents short circuits
  • UL94 V-0 flame retardant rating: meets stringent fire safety requirements for energy storage applications
  • Low viscosity 2500±500 mPa.s: easy to pour and fill complex battery pack geometries
  • Fast curing: 2-4 hours at room temperature, accelerates production efficiency
  • Operating temperature range: -50°C to 200°C, stable performance in extreme climates
  • Good adhesion to metals, plastics, and electronic components
  • Low shrinkage: maintains dimensional stability after curing
Applications:
  • Home energy storage systems
  • Commercial and industrial battery packs
  • Portable power stations
  • Solar energy storage systems
  • Grid-scale battery energy storage
  • Electric vehicle charging stations
Technical Parameters:
  • Component A: White liquid
  • Component B: White liquid
  • Mixing ratio (A:B): 1:1 by weight
  • Viscosity (mixed): 2500±500 mPa.s
  • Pot life: 15-30 minutes
  • Curing time: 2-4 hours (25°C)
  • Hardness: 35-45 Shore A
  • Thermal conductivity: ≥0.6 W/mK
  • Dielectric strength: ≥20 kV/mm
  • Volume resistivity: ≥1.0×10^15 Ω·cm
  • Flame retardancy: UL94 V-0
Packaging:
  • 20kg/set (10kg A + 10kg B)
  • 200kg/set (100kg A + 100kg B)
  • Custom packaging available
Certifications:
  • RoHS compliant
  • REACH compliant
  • UL certified
Storage:
  • Store in cool, dry place below 25°C
  • Shelf life: 12 months from date of manufacture
  • Keep containers tightly sealed when not in use
