        • Product Name: Potting compound silicone
        • Product No.: HY-9405
        • Brand: HY silicone
        • Product Usage:
        • Commodity price:
        • Views : 70


        POTTING COMPOUND SILICONE DESCRIPTION:

               Potting compound silicone is a newly insulating material silicon of silicon compounds.It cures with no heat, no corrosion and little shrinkage. It can be applied to the sealing and pouring of various electronic components, and then forming insulation system.



        POTTING COMPOUND SILICONE APPLICATION:

        HY-9405 Potting compound silicone is suitable for bonded seal of electronic components, power module and control module, which requires waterproof and insulation. It can be broadly used for LED screen, Wind Power Generator, PCB substrate, etc.



        POTTING COMPOUND SILICONE FEATURES:

        1.Room temperature vulcanize, and easy to operate;
        2.Maintain flexibility at a wide temperature range, and excellent insulation performance;
        3.Waterproofing, moisture-proof, mouldproof, dustproof, and fixed components;
        4.Resistance to Chemical dielectric, anti-yellowing, resistance to climate ageing.



        POTTING COMPOUND SILICONE TECHNICAL GUIDELINES:

        1, Pls put part A and part B in separate container and stir evenly before mixing the two part together.
        2, Weight Ratio: part A: part B = 1:1
        3, Deaeration the mixture under 0.08 MPa for 3 minutes.
        4, The temperature influences the curing time of 9301. When in too low temperature, we suggest customers appropriately heat the mixture to accelerate vulcanization.



        POTTING COMPOUND SILICONE WARM TIPS:

        1.The following material may hinder the curing of the product, So pls apply after summary experiment. When necessary, pls clean the application areas.Condensation silicone which not completely cured or organic tin compounds Sulphur, sulfide and sulfur rubber materials.Amine compounds as well as contains the amine materials.Pewters solder flux.
        2. Should be sealed storage.The mixture should be used up at once, avoid causing waste.
        3. Silicone belongs to non-dangerous goods, but keep away from mouth and eyes.
        4. When it gets stratified after a period of storage, Please mix 9301 evenly before using, it
        does not affect the performance.



        POTTING COMPOUND SILICONE SHELF LIFE AND TRANSPORTATION:

        1. Twelve(12) months from date of shipment when stored at 24C in original unopened packages.
        2. This kind of product is non-dangerous product, it can be transported as general chemicals.
        3. Products exceed the storage life should be confirmed normal before using.



           If you have any interest or need more information, welcome to contact now:

          Hotline: 86-755-89948019

                       86-755-89948006

                       86-755-89948294

          E-mail: info@szrl.net              Skype:taylordl828



        POTTING COMPOUND SILICONE TECHNICAL PATAMETERS:

        Features

        Part A

        Part B

        Before Curing

        Appearance

        Transparent Fluid

        Transparent Fluid

        Viscosisty(25℃ cps)

        750±50

        750±50

        Operation

        features

        Mixing Ratio

        1:1

        Viscosisty(after mixing) (cps)

        600~1000

        Operating Time (25℃ min)

        60~120

        Curing Time  (25℃ hr)

        5~10

        After Curing

        Hardness (Shore A)

        0

        Thermal conductivity [W (m·k) ]

        ≥0.2

        Dielectric Strength(KV/mm)

        ≥25

        Permittivity (1.2MHz)

        3.0~3.3

        Volume Resisivity (Ω·cm)

        ≥1.0×1016

        linear expansibility [m/(m·K)]

        ≤2.2×10-4

        Fire Resistance

        94-V0
