        • Product Name: Manual Mold Silicone Rubber
        • Product No.: HY-5 Series Molding Silicone
        • Brand: Hong Ye Silicone
        • Product Usage: Make molds for Plaster, Gypsum, Cement, and Concrete decoration, etc.
        • Commodity price: Discuss personally
        • Views : 140

        MANUAL MOLD SILICONE RUBBER APPLICATIONS: (LINK)
        A. Resin crafts, poly resin crafts, PU crafts, PU resin crafts, unsaturated resin crafts;
        B. Plaster, Gypsum, Cement, and Concrete decoration;

        C. Lighting ornaments, candles crafts;
        D. Plastic toy, stationery gifts crafts industry;
        E. A large statue Buddha, relief, statues Buddha, artifacts copied;
        F. Furniture, furniture decorative materials, building decoration materials;
        G. Large-scale cement mold, artificial fossils Factory, Europe component factory;
        H. Simulation landscapes;
        I. Animals and plants sculpture;
        J. Sandstone crafts;
        K. Model design, product exploitation.


        MANUAL MOLD SILICONE RUBBER FEATURES:
        A. All hardness from 15 to 40 shore A;
        B. Good fluidity, good operability, good for pouring method;
        C. Excellent mechanical properties, in particular tear strength and tensile strength;
        D. Excellent flexibility, easy to demould.

        E. High temperature resistance, high duplication times and repeated use.
        F. Wide range of catalysts/curing agent/hardener for various applications and various requirements on the operation time or curing time.
        G. Good cut-growth resistance;
        H. High durometer hardness;
        I. Low shrinkage;


        MANUAL MOLD SILICONE RUBBER DESRIPTION:
        A.    The manual mold silicon rubber features with the resistance to deformation
        B.   Good tensile strength as well as low shrinkage;
        C.   Time of reproduction determined on the basis of customers.

        MANUAL MOLD SILICONE RUBBER SHELF LIFE:
        Twelve(12) months from date of shipment when stored under 25℃ in the original sealed packages at dry and cool places.


        MANUAL MOLD SILICONE RUBBER PACKAGE:
        1.1kg/jar, 5kgs/drum, 20kgs/drum, 25kgs/drum, 200kgs/drum and vacuumed packing is available.
        2.This kind of product is non-dangerous product, which could be transported as general chemicals.

        MANUAL MOLD SILICONE RUBBER OPERATIONS:
        Firstly process and prepare the model mold or the product to be duplicated, take certain amount of the silicon rubber, add 2-3% solid curing agent, and mix evenly and they are ready for use. One pair of mold can be solidified and formed in 2-3 hours.

        MANUAL MOLD SILICONE RUBBER TECHNICAL DATASHEET:

        Model

        Viscosity

         (cps)

        Hardness

         (A°)

        Tensile

        Strength

        (Mpa)

        Tear

        Strength

        (kN/m)

        Elongation

        (≥%)

        Mixing

        ratio(%)

        Operating

        Time(min)

        Curing

        Time(hr, 25℃)

        HY-530

        17000+3000/-4000

        30±2

        4.5

        22

        ≥300

        2~5

        30~60

        3~5

        HY- 540

        15000+2000/-4000

        35±2

        3.8

        25

        ≥220

        2~5

        30~60

        3~5

        HY- 570

        15000+5000/-5000

        50±2

        3.5

        7

        ≥70

        2~5

        30~60

        3~5



         Note: Above technical datasheet of this product is not the fixed parameters, it's adjustable according to customer's requirements.
