        • Product Name: Liquid RTV-2 Shoe Mold Silicone Rubber
        • Product No.: HY-6 silicone
        • Brand: Hong Ye Silicone
        • Product Usage: Shoe mold silicone rubber is mainly used for shoe molds, sand casting, sole sampling, plaster models
        • Commodity price: Discuss personally
        • Views : 77


        LIQUID RTV-2 SHOE MOLD SILICONE RUBBER FEATURES: (LINK)
        1.Two-component silicone rubber with tin-catalyst
        2.Cured under room temperature
        3.low shrinkage
        4.excellent fexibility & easy demould



        LIQUID RTV-2 SHOE MOLD SILICONE RUBBER APPLICAITONS:

        Shoe mold silicone rubber is mainly used for shoe molds, sand casting, sole sampling, plaster models, simple

        products,products with non-complex patterns, as well as product models with stable size and non-deformation.


        LIQUID RTV-2 SHOE MOLD SILICONE RUBBER USING INSTRUCTION:

        The component A of shoe Mold Silicone Rubber is white flowing liquid and the component B is the curing agent. For

        example, take silicone rubber of 100g and add 2% curing agent for  mixing evenly. After the silicone rubber and the

        curing agent are completely mixed, put the silicon into a vacuum machine for deairing to remove the bubbles. After

        deaired, pouring the liquid silicone rubber into the product to be duplicated or into the mold frame.



        LIQUID RTV-2 SHOE MOLD SILICONE RUBBER NOTES:
        Shoe mold silicone rubber is used for pouring or brushing technique. That is to say, fix the product or sole model to be

        duplicated onto a plane plate, then enclose the plane frame with wooden plates to prevent the leakage of the silicon ,

        mix the silicone rubber and the curing agent evenly according to the mixing ratio of 100 : 2 and pour them onto the sole

        model, then brush evenly with a wooden plate or a brush, and fill up the mold frame with gypsum after the silicone

        rubber is dried.







        LIQUID RTV-2 SHOE MOLD SILICONE RUBBER DATASHEET

        Model

        Viscosity

         (cps)

        Hardness

         (A°)

        Tensile

        Strength

        (Mpa)

        Tear

        Strength

        (kN/m)

        Elongation

        (≥%)

        Mixing

        ratio(%)

        Operating

        Time(min)

        Curing

        Time(hr, 25℃)

        HY-630

        27000+5000

        /-8000

        30±2

        5.3

        31

        ≥400

        2~5

        30~60

        3~5
