        • Product Name: Manual Mold Design Silicone Rubber
        • Product No.: HY-570 manual design silicone
        • Brand: Hong Ye Silicone
        • Product Usage: Used for making manual model design, manual molding, PVC model design, molding design.
        • Commodity price: discuss personally
        • Views : 1581

        HY-570 MANUAL MOLD DESIGN SILICONE RUBBER DESCRIPTION:

        HY-570 manual mold silicone rubber is flowing liquid with consistant quality in whatever color. It consists of two components, component A is base silicone, and component B is curing agent or catalyst. Firstly,prepare the master mold or the product which is ready to be duplicated, take certain amount of the silicone rubber, add 2-5% curing agent, and mix them evenly for use,a mold can be obtained in 2-5 hours. The HY-570 manual molding silicone is mainly applicable to manual molds and duplication of small quantity.



        HY-570 MANUAL MOLD DESIGN SILICONE RUBBER APPLICATION:
        The 570 silicone rubber is mainly applicable to manual mold design, PVC plastic molds, model mold making, cement product molds, melting point alloy molds, alloy toy craftworks, plastic toy craftworks, gifts and stationery, large statues, duplication of cultural relics, shoe sole mold fabrication, pad printing positioning, shock resistance for electronic equipments, etc.



        HY-570 MANUAL MOLD DESIGN SILICONE RUBBER MOLDING OPERATION INSTRUCTION:

               1. Make the mother mold clean and polished.

          2. Weigh the two parts exactly by  electronic scale.

               3. Mix the two parts thouroughly.

               4. Exhaust the bubbles by certain machine or by reducing the volume of the added catalyst.

               5. Molding in the way of pouring or brushing.

               6. If necessary, a outer shell shall be made to protect the silicone mold from deformation.

                (Note: we can provide mold making tutorial for customer by instruction or video )



        HY-570 MANUAL MOLD DESIGN SILICONE RUBBER PACKAGE:

        25KG/drum vacuum packing for part A +1kg/ bottle catalyst for part B
        200KG/drum packing for part A +1kg/ bottle catalyst for part B

        Note: 1kg/jar, 5kgs/drum, 20kgs/drum, 25kgs/drum, 200kgs/drum and vacuum package is available


        HY-570 MANUAL MOLD DESIGN SILICONE RUBBER SHELF LIFE:
        Twelve(12) months when stored under dry and cool place by original package under 25℃





        HY-570 MANUAL MOLD DESIGN SILICONE RUBBER TECHNICAL PARAMETERS:

        Model

        Appearance

        Viscosity (cps)

        Hardness (A°)

        Tensile Strength (Mpa)

        Tear Strength (KN/m)

        Elongation (%)

        Mixing ratio (%)

        Pot life (H)

        Demould

         time(H)

        HY-570

        White

        50000+1 0000/-2 0000

        50±3

        3.5

        7

        70

        2~3

        0.5

        3~5

         Note: Above technical datasheet of rtv mould making silicone rubber HY-570 is not the fixed parameters, it's adjustable according to customer's requirements.
