        • Product Name: Transparent addition potting compound
        • Product No.: HY-9305
        • Brand: HY silicone
        • Product Usage: Applying for the surface of PC (Poly-carbonate), PP, ABS, PVC, Metal, etc.
        • Commodity price:
        • Views : 69



        TRANSPARENT POTTING COMPOUND DESCRIPTION:

              Transparent addition potting compound is a kind of  Inherent flame resistance, two components addition cured potting silicone with heat-conducting. It cures with both on room temperature and heated temperature.



        TRANSPARENT POTTING COMPOUND APPLICATION:
        • Applying for the surface of PC (Poly-carbonate), PP, ABS, PVC, Metal, etc.
        • High powered electronic encapsulation and DC/DC module and circuit board which requires heat dissipation and high temperature resistance.
        • Insulation, waterproof and bonding of general electronic components.
        • Filling for LED, LCD electronic display, circuit board, PCB substrate, etc.
        • Outdoor protection for LED screen.



        TRANSPARENT POTTING COMPOUND CHARACTERISTICS:

        Transparent addition potting compound is a kind of two components (1:1mixing ratio) addition cure silicone with the Characteristics of heat-conducting, low viscosity, Inherent flame resistance, waterproofing, etc. It can cure both at room temperature and heated temperature and the curing time can be accelerated by higher temperature.



        TRANSPARENT POTTING COMPOUND PACKAGING:
        Standard packing for potting compound silicone is 22kg/set (Part A 20kg + Part B 2kg)



        TRANSPARENT POTTING COMPOUND SHELF LIFE AND TRANSPORTATION:
        1. Twelve(12) months from date of shipment when stored at 24C in original unopened packages.
        2. This kind of product is non-dangerous product, it can be transported as general chemicals.
        3. Products exceed the storage life should be confirmed normal before using.



           If you have any interest or need more information, welcome to contact now:

          Hotline: 86-755-89948019

                       86-755-89948006

                       86-755-89948294

          E-mail: info@szrl.net              Skype:taylordl828



        TRANSPARENT POTTING COMPOUND STANDARD DATASHEET:

        Product Model

        HY-9305

        Properties index

        Part A

        Part B

        Appearance

        Transparent

        Before curing

        Mixed Viscosity(mPa.s)

        500±100

        Features

        operation

        Mix Ratio(A:B)

        1:1

        Operating Time(25℃ /mins)

        60~120

        Curing time(hrs,25℃)

        6~8

        Curing time(hrs,80℃)

        20

        Hardness (shore A)

        5±3



        After Curing

        Linear expansibility[m/(m·K)]

        ≤2.2×10-4

        Thermal Conductivity[W(m·K)]

        ≥0.2

        Dielectric Strength(kV/mm)

        ≥25

        Dielectric permittivity(1.2MHz)

        3.0~3.3

        Volume resistivity(Ω·cm)

        ≥1.0×1016

        Fire Resistance

        UL94-V1
