        • Product Name: Silicone rubber compound
        • Product No.: HY-9310
        • Brand: HY silicone
        • Product Usage: electronic components, power module and control module
        • Commodity price:
        • Views : 64


        SILICONE RUBBER COMPOUND DESCRIPTION:

               Silicone rubber compound is a kind of low viscosity, Inherent flame resistance, two components addition cured potting silicone with heat-conducting. It cures with both on room temperature and heated temperature.



        SILICONE RUBBER COMPOUND APPLICATION:
        HY-9310 Silicone rubber compound  is suitable for bonded seal of electronic components, power module and control module, which requires waterproof and insulation. It can be broadly used for LED screen, Wind Power Generator, PCB substrate, etc.



        SILICONE RUBBER COMPOUND FEATURES:

        1.Room temperature vulcanize, and easy to operate;
        2.Maintain flexibility at a wide temperature range, and excellent insulation performance;
        3.Waterproofing, moisture-proof, mouldproof, dustproof, and fixed components.



        SILICONE RUBBER COMPOUND WARM TIPS:
        1.The following material may hinder the curing of the product, So pls apply after summary experiment. When necessary, pls clean the application areas.
          Condensation silicone which not completely cured or organic tin compounds
          Sulphur, sulfide and sulfur rubber materials.
          Amine compounds as well as contains the amine materials.
          Pewters solder flux.
        2. Should be sealed storage.The mixture should be used up at once, avoid causing waste.
        3. Silicone belongs to non-dangerous goods, but keep away from mouth and eyes.
        4. When it gets stratified after a period of storage, Please mix 9310 evenly before using, it does not affect the performance.



        SILICONE RUBBER COMPOUND PACKAGE:

        25Kg/pail, 200kg/pail



        SILICONE RUBBER COMPOUND SHELF LIFE AND TRANSPORTATION:

        1. Twelve(12) months from date of shipment when stored at 24C in original unopened packages.
        2. This kind of product is non-dangerous product, it can be transported as general chemicals.
        3. Products exceed the storage life should be confirmed normal before using.



           If you have any interest or need more information, welcome to contact now:

          Hotline: 86-755-89948019

                       86-755-89948006

                       86-755-89948294

          E-mail: info@szrl.net              Skype:taylordl828



        SILICONE RUBBER COMPOUND TECHNICAL PARAMETERS:

        Features

        Part A

        Part B

        Before Curing

        Appearance

        Transparent Fluid

        Transparent Fluid

        Viscosisty(25℃ cps)

        500±100

        500±100

        Operation

        features

        Mixing Ratio

        1:1

        Viscosisty(after mixing) (cps)

        600~1000

        Operating Time (25℃ min)

        30

        Curing Time  (60℃ min)

        25

        After Curing

        Hardness (Shore A)

        10±3

        Thermal conductivity [W (m·k) ]

        ≥0.2

        Dielectric Strength(KV/mm)

        ≥25

        Permittivity (1.2MHz)

        3.0~3.3

        Volume Resisivity (Ω·cm)

        ≥1.0×1016

        linear expansibility [m/(m·K)]

        ≤2.2×10-4

        Fire Resistance

        94-V1
