        • Product Name: Silicone rubber for potting
        • Product No.: HY-9320
        • Brand: HY silicone
        • Product Usage: Applying for the surface of PC (Poly-carbonate), PP, ABS, PVC, Metal, etc.
        • Commodity price:
        • Views : 59


        POTTING SILICONE RUBBER DESCRIPTION:

        Potting Silicone Rubber is a kind of low viscosity, Inherent flame resistance, two components addition cured potting silicone with heat-conducting. It cures with both on room temperature and heated temperature.


        POTTING SILICONE RUBBER APPLICATION:

        • Applying for the surface of PC (Poly-carbonate), PP, ABS, PVC, Metal, etc.
        • High powered electronic encapsulation and DC/DC module and circuit board which requires heat dissipation and high temperature resistance.
        • Insulation, waterproof and bonding of general electronic components.
        • Filling for LED, LCD electronic display, circuit board, PCB substrate, etc.
        • Outdoor protection for LED screen.



        POTTING SILICONE RUBBER CHARACTERISTICS:

        Transparent addition potting compound is a kind of two components (1:1mixing ratio) addition cure silicone with the Characteristics of heat-conducting, low viscosity, Inherent flame resistance, waterproofing,etc.It can cure both at room temperature and heated temperature and the curing time can be accelerated by higher temperature.


        POTTING SILICONE RUBBER PACKAGING:
        Standard packing for potting compound silicone is 22kg/set (Part A 20kg + Part B 2kg)



        POTTING SILICONE RUBBER SHELF LIFE AND TRANSPORTATION:

        1. Twelve(12) months when stored at 24C in tightly closed original packages.
        2. This kind of product is non-dangerous product, which could be transported as general chemicals.
        3. Storage beyond the expired date doesnot necessarily mean that the product is no longer usable. In this case however, the properties required for the intended use must be checked for quality assurance reasons.



           If you have any interest or need more information, welcome to contact now:

          Hotline: 86-755-89948019

                       86-755-89948006

                       86-755-89948294

          E-mail: info@szrl.net              Skype:taylordl828



        POTTING SILICONE RUBBER STANDARD DATASHEET:

        Product Model

        HY-9320

        Properties index

        Part A

        Part B

        Appearance

        Transparent

        Before curing

        Mixed Viscosity(mPa.s)

        500±100

        Features

        operation

        Mix Ratio(A:B)

        1:1

        Operating Time(25℃ /mins)

        60~120

        Curing time(hrs,25℃)

        6~8

        Curing time(hrs,80℃)

        20

        Hardness (shore A)

        20±3



        After Curing

        Linear expansibility[m/(m·K)]

        ≤2.2×10-4

        Thermal Conductivity[W(m·K)]

        ≥0.2

        Dielectric Strength(kV/mm)

        ≥25

        Dielectric permittivity(1.2MHz)

        3.0~3.3

        Volume resistivity(Ω·cm)

        ≥1.0×1016

        Fire Resistance

        UL94-V1
