        • Product Name: Electronic Potting Silicone
        • Product No.: HY 9330
        • Brand: HY silicone
        • Product Usage:
        • Commodity price:
        • Views : 97


        ELECTRONIC POTTING SILICONE DESCRIPTION:

               HY-9330 is a kind of inherent flame resistance, two components addition cured potting silicone with heat-conducting. It cures with both on room temperature and heated temperature. It has the feature of the higher temperature the faster of the curing time. It can be applied to electronic components for insulation, waterproofing, fixed and flame retardant. It mainly applied in electronic components surface with materials of  PC(Poly-carbonate)、PP、ABS、PVC, etc. and metal materials.



        ELECTRONIC POTTING SILICONE TECHNICAL GUIDELINES:

        1, Typical Application:

        HY 9330 could be applied to high powered electronics, DC/DC module and circuit board which requires heat dissipation and high temperature resistance.
        It can be broadly used for LED screen, Wind Power Generator, PCB substrate, etc. Pls put part A and part B in separate container and stir evenly before mixing the two part together.
        2, Mixing Ratio: part A: part B = 1:1
        3, Deceleration the mixture in vacuum pump under 0.08 MPa for 3-5 minutes.Then the mixture could be used for pouring.
        4, Pls note that the thickness of the silicone affects the curing time. If the silicone used is a little thick,then the curing time will be a little longer.The temperature also affects the curing time.When in lower temperature, we suggest customers appropriately heat the mixture to accelerate vulcanization. With temperature of 80~100℃, the silicone will cure in 15 to 20minutes; while in 25℃ room temperature, the silicone will cure around 8 to 10 hours.



        ELECTRONIC POTTING SILICONE PACKAGE:

        20Kg/pail for Part A  +20Kg/pail for Part A in one set



        ELECTRONIC POTTING SILICONE SHELF LIFE AND TRANSPORTATION:

        1. Twelve(12) months when stored at 24C in tightly closed original packages.
        2. This kind of product is non-dangerous product, which could be transported as general chemicals.
        3. Storage beyond the expired date does not necessarily mean that the product is no longer usable. In this case however, the properties required for the intended use must be checked for quality assurance reasons.



           If you have any interest or need more information, welcome to contact now:

          Hotline: 86-755-89948019

                       86-755-89948006

                       86-755-89948294

          E-mail: info@szrl.net              Skype:taylordl828



        ELECTRONIC POTTING SILICONE TECHNICAL PARAMETERS:

        Features

        Part A

        Part B

        Before Curing

        Appearance

        Transparent

        Transparent



        Operation features

        Mixing Ratio

        1:1

        Operating Time(25℃  mins)

        60-120

        Curing time (hours,25℃)

        8-10

        Curing time(80℃  mins)

        20

        Hardness(Shore  A)

        30±5





        After Curing

        Thermal conductivity [W(m·K)]

        ≥0.8

        Dielectric Strength(KV/mm)

        ≥25

        Permittivity(1.2MHz)

        3.0~3.3

        Volume Resisivity(Ω·cm)

        ≥1.0×1016

        linear expansibility [m/(m·K)]

        ≤2.2×10-4

        Fire Resistance

        94-V1

        (Pls note: the above data for this product in 25 ℃ temperature, 55 percent humidity
        conditions, for reference. The accurate data is measured by customers when using.)
