        • Product Name: Silicone Rubber for Rapid Prototyping
        • Product No.: Rapid Prototyping Silicone
        • Brand: Hong Ye Silicone
        • Product Usage: it called clear silicone on making prototype field with transparent color , Longer service life.
        • Commodity price: Discuss personally
        • Views : 91

        SILICONE RUBBER FOR RAPID PROTOTYPING APPLICATION:
            Liquid silicone for prototype design is addition cure / platinum catalyst molding silicone that cures at both room temperature and heated temperature, with transparent color which will help you on rapid prototyping, so it’s also called clear silicone on making prototype field.

        SILICONE RUBBER FOR RAPID PROTOTYPING DESCRIPTION:
        RTV-2 Molding materials are general called two-component room temperature vulcanization liquid silicone rubber with excellent fluidity and good operational performance. Add part B into part A, stir the mixture evenly, then pour the liquid mixture to the mother mold, then after 2-6 hours, a flexible silicone rubber mold will be obtained a with resistance to deformation, high-temperature, acid and alkali and expansion.

        SILICONE RUBBER FOR RAPID PROTOTYPING ADVANTAGES:
        - FDA certified, platinum cure silicone
        - Clear / translucent silicone rubber
        - Suitable hardness around 40 shore A.
        - Low shrinkage less than 0.1%
        - Longer service life (5 years)
        - High temperature resistance
        - Never have oily problem


        SILICONE RUBBER FOR RAPID PROTOTYPING NOTICE:
        1. In order to avoid no curing problem, it cannot mix with condensation cure silicone rubber, organic matter which is containing N, S, P organics and ionic compound like Sn, As,Hg, Ph. What’s more, please do not smoke when operating the platinum cure silicone rubber, otherwise, it will cause to no curing problem too.
        2, The solidification of platinum cure silicone rubber is particularly affected by temperature, higher the temperature is, faster the curing time will be.

        SILICONE RUBBER FOR RAPID PROTOTYPING PACKAGE:
        1 kg/jar, 5 kg/drum, 20 kg/drum, 200 kg/drum and vacuum package is available.

        SILICONE RUBBER FOR RAPID PROTOTYPING SHELF LIFE:
        Twelve(12) months when stored under dry & cool place by original package under 25℃.


        SILICONE RUBBER FOR RAPID PROTOTYPING TECHNICAL DATASHEET:

        Model

        Viscosity

         (cps)

        Hardness

         (A°)

        Tensile Strength

             (Mpa)

        Tear Strength

        (kN/m)

        Elongation (≥%)

        Mix ratio

        Handing time(min)

        Curing Time

        (hr, 25℃)

        HY-E630

        6500+1500

        /-2000

        30±2

        9

        17

        ≥350

        1:1

        /10:1

        30~60

        3~5

        HY-E635

        8000+2000

        /-3000

        35±2

        9

        17

        ≥350

        1:1

        /10:1

        30~60

        3~5

        HY-E640

        8000+2000

        /-3000

        40±3

        9

        17

        ≥300

        1:1

        /10:1

        30~60

        3~5

        HY-E650

        11000+3000

        /-4000

        50±3

        8

        16

        ≥200

        1:1

        /10:1

        30~60

        3~5

        HY-E660

        16000+5000

        /-8000

        60±3

        6

        11

        ≥80

        1:1

        /10:1

        30~60

        3~5



        Note: Above technical datasheet doesn’t include all of our products, and it’s not the fixed data, they can be adjustable according to

         customer’s requirement.
