        • Product Name: Silicone rubber for shoe sole mold
        • Product No.: HY-530
        • Brand: Hong Ye Silicone
        • Product Usage: shoe sole Molding silicone rubber
        • Commodity price: Discuss personally
        • Views : 237

        Features of Silicone rubber for shoe sole mold
        A. mainly used for shoe soles mold making
        B. Two-component silicone rubber with tin-catalyst
        C. Cured under room temperature
        D. low shrinkage
        E. excellent fexibility & easy demould

        Applications of Silicone rubber for shoe sole mold
        Shoe mold silicone rubber is mainly used for shoe molds, sand casting, sole sampling, plaster models, simple products,

        products with non-complex patterns, as well as product models with stable size and non-deformation.

        Using Instruction of Silicone rubber for shoe sole mold
        The component A of shoe Mold Silicone Rubber is white flowing liquid and the component B is the curing agent. For example,

        take silicone rubber of 100g and add 2% curing agent for  mixing evenly. After the silicone rubber and the curing agent are

        completely mixed, put the silicon into a vacuum machine for deairing to remove the bubbles. After deaired, pouring the liquid

        silicone rubber into the product to be duplicated or into the mold frame.

        Notes:Shoe mold silicone rubber is used for pouring or brushing technique. That is to say, fix the product or sole model to be

        duplicated onto a plane plate, then enclose the plane frame with wooden plates to prevent the leakage of the silicon , mix the

        silicone rubber and the curing agent evenly according to the mixing ratio of 100 : 2 and pour them onto the sole model, then

        brush evenly with a wooden plate or a brush, and fill up the mold frame with gypsum after the silicone rubber is dried



        Techinical datasheet of Silicone rubber for shoe sole mold


        Model

        Viscosity
         (cps)

        Hardness
         (A°)

        Tensile
        Strength
        (Mpa)

        Tear
        Strength
        (kN/m)

        Elongation
        (≥%)

        Mixing
        ratio(%)

        Operating
        Time(min)

        Curing
        Time(hr, 25℃)

        HY-530

        17000+3000/-4000

        30±2

        4.5

        22

        ≥300

        2~5

        30~60

        3~5
