        • Product Name: Pad print silicone for stationery
        • Product No.: HY-902
        • Brand: HY silicone
        • Product Usage: pad printing for stationery, toys, etc
        • Commodity price:
        • Views : 951



        DESCRIPTION OF PAD PRINT SILICONE FOR STATIONERY:

        The HY902 pad print silicone rubber with the merits of wear resistance, high temperature resistance and good printing effect, is processed through high-temperature machining. The product is mainly applicable to stationery, toys, electroplating products,and products with irregular pattern. The silicone pad is a satisfactory carrier which pick the patterns on the steel plate onto the stationery products' surface. Hongye technology Ltd. is a well-known pad silicone supplier in China for many years.




        How to operate rubber pad print process  ( link )

        The reason why the silicone pad can not pick the printing ink well.

          You must have used the hard rubber pad to pick the fine and complicated patterns from the steel substrate, resulting in bad effect of picking printing ink.



        The reason why the printing ink can not be transfered from the rubber pad to the plastic products' surface.

                 It is common that two products or so appear to be unable to catch the patterns from the pad among every ten products. The phenomenon  is normal, because the plastic injection molding machine will spray the release agent onto the steel moulds' surface after finishing every ten plastic products or so. If we don't clean the plastic products' surface before pad printing process, the printing effects will be bad.


        PACKAGE OF PAD PRINT SILICONE FOR STATIONERY:

        20KG/drum vacuum packing for part A +1kg/ bottle catalyst for part B



        SHELF LIFE OF PAD PRINT SILICONE FOR STATIONERY:
        Eight to Ten(8-10) months when stored under dry and cool place by original package under 25℃.



           If you have any interest or need more information, welcome to contact now:

          Hotline: 86-755-89948019

                       86-755-89948006

                       86-755-89948294



          E-mail: info@szrl.net              Skype:taylordl828

        TECHNICAL PARAMETERS OF PAD PRINT SILICONE FOR STATIONERY:

        Model

        Viscosity
         (cps)

        Hardness
         (A°)

        Tensile
        Strength
        (Mpa)

        Tear
        Strength
        (kN/m)

        Elongation
        (≥%)

        Mixing
        ratio

        Operating
        Time(min)

        Curing
        Time(Min, 25℃)

        HY-902

        32000+3000/-5000

        30

        5

        29

        ≥400

        2~5 %

        30~60

        3~5



        Note: Above technical datasheet of Pad print silicone for stationery is not the fixed parameters, it's adjustable according

        to customer's requirements.
