        • Product Name: Silicone Rubber for Transfer Pad
        • Product No.: HY-916
        • Brand: Hong Ye Silicone
        • Product Usage: Making silicone pad, printing pad, transfer pad
        • Commodity price: discuss personally
        • Views : 1140

        DESCRIPTION of SILICONE RUBBER FOR TRANSFER PAD:

        The silicone printing pad mad which is made from HY-916 is a kind of soft pad, around 14 shore A.

        Is of excellent resistance against wear, good printing effect, high temperature resistance, etc.

        The product is mainly applicable to electroplating products, electronic toys, trademarks and irregular pattern printing. The silicone pad is a perfect carrier which transfer printing the patterns on the steel plate onto you own products' surface. No matter what shape of the objects' surface is, including cylindrical, spherical, compound angles, concave, convex, textures, and so on. Compared with our other products with different  model number, the HY916 is characterized by soft hardness, which is only around 15  A°. The HY-916 is a condensation type.



        Operation Instruction for making transfer pad ( link: how to make a silicone pad )



        The factors that make the printing effect appear vague or incomplete:

        1. The pad printing pads may be too hard to pick full patterns from the steel plate substrate(we can imagine the picking process in our mind). As a result, if you need to transfer the complecate and delicate from the substrate to your own products' surface, just make the hardness small,namely,soft printing head.

        2. Perhaps too much water is contained in the printing ink, resulting in bad effect of spots. We suggest that you should wash your ink container, and change the old printing ink and buy a new one.



        PACKAGE of SILICONE RUBBER FOR TRANSFER PAD:
        20KG/drum or 25KG/drum or 200KG/drum for part A +1kg/ bottle catalyst for part B



        SHELF LIFE of SILICONE RUBBER FOR TRANSFER PAD:
        Twelve (12) months when stored under dry and cool place by original package under 25℃.





        TECHNICAL PARAMETERS of SILICONE RUBBER FOR TRANSFER PAD:

        Model

        Appearance

        Viscosity

        (cps)

        Hardness (A°)

        Tensile Strength (Mpa)

        Tear Strength (KN/m)

        Elongation (%)

        Mixing Ratio

        (%)

        Pot life

         (H)

        Demould  time (H)

        HY-916

        red / yellow
         /  white/green

        55000+5000

        /-8000

        14

        3.4+1/-0.3

        25+5/-2

         ≥510

        2~3

        0.5

        2~4

        Note: Above technical datasheet of silicone rubber for transfer pad is not the fixed parameters, and it's adjustable according to customer's requirements.
