        • Product Name: Robot Silicone Rubber
        • Product No.: HY-E series robort silicone
        • Brand: HY silicone
        • Product Usage:
        • Commodity price:
        • Views : 219



        SILICONE RUBBER FOR ROBOT MAKING DESCRIPTION:

        Silicone rubber for robot making is a kind of two-component addition-type silicone rubber, consisted of part A and part B of flowable silicone rubber, which can be cured at room temperature or heated fast curing. It is used to make the skin of the robot just like human skin in color, hardness and elasticity. It is soft to touch, no deformation and easy to make different styles. It is widely applied for various simulate silicone robot, concierge simulation robot and household robots.



        SILICONE RUBBER FOR ROBOT MAKING APPLICATION:

        Silicone rubber for robot making is mainly used for the simulate human body model, simulate body masks, body prostheses, human organs, sex toys, artificial breast, shoulder pads, etc. It can also be used to make food mold, high-grade silicone products as it is food grade. It is soft to touch, no deformation and easy to make different styles.



        SILICONE RUBBER FOR ROBOT MAKING CHARACTERISTIC:

        1, soft to touch, no deformation and good elasticity.

        2, Non-toxic, odorless, food-grade certified by the FDA.

        3, High tensile strength and tear strength, anti-aging, high duplication times.

        4, Good air permeability and low shrinkage (≤0.1%).

        5, Easy for operating, easy for pouring; can be cured at room temperature or heat curing.

        6, Not restricted by the thickness of products, elastic properties can keep under -65 ℃ -200 ℃.



        SILICONE RUBBER FOR ROBOT MAKING OPERATION:

        Weigh part A and part B with the mix ratio of 1:1. After vacuum-pumping, it can be casting. At room temperature, the operating time is about 0.5-3 hours, curing time is about 12-24hours. When heating to 80-120℃, it can be completely cured in a few minute. As for quick-drying silicone rubber(at room temperature), the operating time is less 20 minutes and curing time is about 1 hour.



        SILICONE RUBBER FOR ROBOT MAKING NOTES:

        1.As it's easy to cause uncured problem, pls clean up all the tools which had mixed with condensation cure silicone rubber to avoid uncuring problem.

        2.Do not add any pigment or powder into the platinum cure silicone rubber before testing to prevent uncured problem.

        3.The mixing ratio(1:1 or 10:1) must in strict accordance with the ratio in case of the changing of the hardness.

        4.Do not add water, organic tin catalyst, acids, alkali and other organic compounds containing sulfur, phosphorus and nitrogen, as they can affect the process of curing.



        SILICONE RUBBER FOR ROBOT MAKING PACKAGE:

        20kg/drum, 200kg/drum



        SILICONE RUBBER FOR ROBOT MAKING SHELF LIFE:

        Twelve(12) months when stored under dry and cool place by original package under 25℃

        SILICONE RUBBER FOR ROBOT MAKING PARAMETER:

        Model

        Color

        Vocosity

        (mPa.s)

        Hardness

          ( Shore A )

        Tensile-

        strength

         (MPa)

        Tear strength

        (Kn/m)

        Elongation

        (%)

        Mix ratio

        Operation

         time(h)

        Curing time

        (h)

        HY-E605

        Flesh tone

        1000

        5±2

        2.2

        8±2

        900

        1:1

        0.5

        2-4

        HY-E610

        Flesh tone

        1500

        10±2

        3.2

        12±2

        700

        1:1

        0.5

        2-4

        HY-E615

        Flesh tone

        6000

        15±2

        4.2

        12±2

        470

        1:1

        0.5

        2-4

        HY-E620

        Flesh tone

        8000

        20±2

        4.7

        20±2

        520

        1:1

        0.5

        2-4

        HY-E625

        Flesh tone

        8000

        25±2

        5.2

        20±2

        470

        1:1

        0.5

        2-4

        HY-E630

        Flesh tone

        9000

        30±2

        5.2

        12±2

        470

        1:1

        0.5

        2-4

        Note: Above technical datasheet of HY-E6 serise is not the fixed parameters, and it's adjustable according to customer's requirements
