        • Product Name: Aerospace silicone rubber
        • Product No.: HY-E series aerospace silicone
        • Brand: HY silicone
        • Product Usage:
        • Commodity price:
        • Views : 106


        SILICONE RUBBER FOR AEROSPACE INDUSTRY DESCRIPTION:

        Silicone rubber for aerospace industry is a kind of two-component addition silicone material, consisted of part A and part B of flowable rtv silicone rubber. which can be cured at room temperature or heated fast curing. It is a translucent, odorless, non-toxic addition liquid silicone raw materials, not restricted by the thickness of the products, depth curing, pouring or brushing, easy and convenient operation.



        SILICONE RUBBER FOR AEROSPACE INDUSTRY APPLICATION:

        It is widely used in most of the exposure system on the plane, aerospace aircraft, silicone cables, cockpit, landing gear and aerial-photography class, such as cable sheathing used in airplanes and aircraft, hydraulic systems, engine cylinders, pilots and astronauts life support system of the cylinder seals, silicone tube, silicone hoses, electrical insulating liner and hot air ducts are made of silicone rubber.



        SILICONE RUBBER FOR AEROSPACE INDUSTRY CHARACTERISTIC:

        1. Not restricted by the thickness of the products, depth curing
        2. Excellent chemical resistance, temperature resistance performance can reach -50 ~ 250 ℃
        3. Low shrinkage (≤0.1%)

        4. High tensile strength, tear strength, can be used hundreds of time
        5. Good liquidity, easy for pouring; it can be cure at room temperature or heating



        SILICONE RUBBER FOR AEROSPACE INDUSTRY OPERATION AND NOTES:

        1.Weigh part A& part B with mix ratio of 1:1, then stir it evenly. After Vacuum-pumping.it can be casting. At room temperature (28 ℃) ,the operating time is about 30 minutes and it will be totally cured after 2-3 hours . When heating to 60-120 degrees, it can be completely cured in a few minute.

        2.Clean all the tools before using if it is used for condensation silicone rubber as before. Otherwise, the addition cure silicone rubber can not be cured.
        3. Make a test before extensive using.
        4 .Do not add any pigment or powder into the addition cure silicone rubber before testing to prevent uncuring.
        5.Weigh the silicone rubber according to the mixing ratio exactly, otherwise the hardness will be changed.
        6. Do not add water, organic tin catalyst, acids, alkali and other organic compounds containing
        sulfur, phosphorus and nitrogen, as they can affect the process of curing.



        SILICONE RUBBER FOR AEROSPACE INDUSTRY PACKAGE:

        20kg/drum, 200kg/drum



        SILICONE RUBBER FOR AEROSPACE INDUSTRY SHELF LIFE:

        Twelve(12) months when stored under dry and cool place by original package under 25℃



           If you have any interest or need more information, welcome to contact now:

          Hotline: 86-755-89948019

                       86-755-89948006

                       86-755-89948294

          E-mail: info@szrl.net              Skype:taylordl828



        SILICONE RUBBER FOR AEROSPACE INDUSTRY TECHNICAL PARAMETERS:

        Model

        Color

        Vocosity

        (mPa.s)

        Hardness

        ( Shore A )

        Tensile-

        strength

        (MPa)

        Tear

        strength

        (Kn/m)

        Elongation

        (%)

        Mix

        ratio

        Operation

         time(h)

        Curing

         time

        (h)

        HY-E620

        Translucent

        8000

        20±2

        4.7

        20±2

        ≥520

        1:1

        0.5

        2-4

        HY-E625

        Translucent

        8000

        25±2

        5.2

        20±2

        ≥470

        1:1

        0.5

        2-4

        HY-E630

        Translucent

        9000

        42±2

        5.2

        12±2

        ≥470

        1:1

        0.5

        2-4

        HY-E635

        Translucent

        10000

        35±2

        5.8

        15±2

        ≥450

        1:1

        0.5

        2-4

        HY-E640

        Translucent

        12000

        50±5

        6.2

        12±2

        ≥320

        1:1

        0.5

        2-4



        (Notes :The above parameters are all for your reference, the viscosity, operating time, hardness can be adjusted

        according to customers’ needs. If you have any special requirements, please contact us.)
